• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Mains lead rating: H05VV-F m
• Protection class: Class I
• Outlet diameter: 120mm/150mm mm
• Outlet diameter: It is best to use the AED6 (150mm) ducting kit rather than the AED5 (120mm) with the adaptor. This keeps noise levels to a minimum. mm
• Outlet diameter: 150mm with a 120mm reducer mm
• Rated electrical power: 104 W
• Motor Input: 100.0000 W
• Rated electrical power: 104 W

Optional Accessories

• Ducting kit code: 120mm, AED 51/53/54
• Ducting kit code: 150mm, AED 61/63/64
• Charcoal filter for re-circulation: CHA12 (pack of 1)
• Charcoal filter for recirculation : 0

Fitting Notes

• Fitting note: please ensure that you check the ceiling height is sufficient to allow the required clearnace between the hob and extractor

Filters

• Charcoal filters: CHA12 (pack of 1)
• Number of layers: 4
• Number of grease filters: 1
• Number of charcoal filters (optional): 1
• Ducting kit: AED61/63/64 or AED51/53/54 with adaptor
• Charcoal filter code: CHA12 (pack of 1)

Extraction Rates And Noise

• Extraction rate at first speed: 218 m3/hr
• Noise level at first speed: 50 dBA
• Extraction rate at second speed: 302 m3/hr
• Noise level at second speed: 58 dBA
• Extraction rate: 391 m3/hr
• Noise level: 60 dBA
• Extraction rate at third speed: 391 m3/hr
• Noise level at third speed: 60 dBA

Lighting

• Type of light: LED
• Number of lights: 2
• Additional lighting: 0

Energy

• Energy rating: D
•
